Абсолютные энкодеры AFS/AFM60 Sick

Показано товаров: 10 из 625
Артикул: 150047
  • High-resolution absolute encoders with up to 30 bits (AFM60) or up to 18 bits (AFS60)
  • Face mount flange, servo flange, blind or through hollow shaft
  • SSI, SSI + Incremental or SSI + Sin/Cos interface
  • Programmable resolution and offset (dependent on type)
  • Connection system: M12, M23 connector or cable outlet
  • Enclosure rating: IP 67 (housing), IP 65 (shaft)
  • Operating temperature: -30 °C to +100 °C (depends on type)
Артикул: 150069
  • High-resolution, 30-bit absolute encoder (18 bit singleturn and 12 bit multiturn)
  • Device Level Ring (DLR functionality)
  • Extensive diagnostics: Min/max values for temperature, position, speed. Operating hours counter, display of flags, alarms and warnings using e.g. a fault header (32 bit)
  • Status display via 5 duo LEDs
  • Rotary axis function
  • IP address via DHCP / DEC switches
  • Ethernet/IP interface (extended profile 0x22)
  • Function block
Артикул: 150070
  • High-resolution absolute encoders with up to 30 bits (AFM60) or up to 18 bits (AFS60)
  • Face mount flange, servo flange, blind or through hollow shaft
  • SSI, SSI + Incremental or SSI + Sin/Cos interface
  • Programmable resolution and offset (dependent on type)
  • Connection system: M12, M23 connector or cable outlet
  • Enclosure rating: IP 67 (housing), IP 65 (shaft)
  • Operating temperature: -30 °C to +100 °C (depends on type)
Артикул: 150122
  • High-resolution absolute encoders with up to 30 bits (AFM60) or up to 18 bits (AFS60)
  • Face mount flange, servo flange, blind or through hollow shaft
  • SSI, SSI + Incremental or SSI + Sin/Cos interface
  • Programmable resolution and offset (dependent on type)
  • Connection system: M12, M23 connector or cable outlet
  • Enclosure rating: IP 67 (housing), IP 65 (shaft)
  • Operating temperature: -30 °C to +100 °C (depends on type)
Артикул: 150168
  • High-resolution absolute encoders with up to 30 bits (AFM60) or up to 18 bits (AFS60)
  • Face mount flange, servo flange, blind or through hollow shaft
  • SSI, SSI + Incremental or SSI + Sin/Cos interface
  • Programmable resolution and offset (dependent on type)
  • Connection system: M12, M23 connector or cable outlet
  • Enclosure rating: IP 67 (housing), IP 65 (shaft)
  • Operating temperature: -30 °C to +100 °C (depends on type)
Артикул: 150169
  • High-resolution absolute encoders with up to 30 bits (AFM60) or up to 18 bits (AFS60)
  • Face mount flange, servo flange, blind or through hollow shaft
  • SSI, SSI + Incremental or SSI + Sin/Cos interface
  • Programmable resolution and offset (dependent on type)
  • Connection system: M12, M23 connector or cable outlet
  • Enclosure rating: IP 67 (housing), IP 65 (shaft)
  • Operating temperature: -30 °C to +100 °C (depends on type)
Артикул: 150170
  • High-resolution absolute encoders with up to 30 bits (AFM60) or up to 18 bits (AFS60)
  • Face mount flange, servo flange, blind or through hollow shaft
  • SSI, SSI + Incremental or SSI + Sin/Cos interface
  • Programmable resolution and offset (dependent on type)
  • Connection system: M12, M23 connector or cable outlet
  • Enclosure rating: IP 67 (housing), IP 65 (shaft)
  • Operating temperature: -30 °C to +100 °C (depends on type)
Артикул: 150205
  • High-resolution absolute encoders with up to 30 bits (AFM60) or up to 18 bits (AFS60)
  • Face mount flange, servo flange, blind or through hollow shaft
  • SSI, SSI + Incremental or SSI + Sin/Cos interface
  • Programmable resolution and offset (dependent on type)
  • Connection system: M12, M23 connector or cable outlet
  • Enclosure rating: IP 67 (housing), IP 65 (shaft)
  • Operating temperature: -30 °C to +100 °C (depends on type)
Артикул: 150214
  • High-resolution absolute encoders with up to 30 bits (AFM60) or up to 18 bits (AFS60)
  • Face mount flange, servo flange, blind or through hollow shaft
  • SSI, SSI + Incremental or SSI + Sin/Cos interface
  • Programmable resolution and offset (dependent on type)
  • Connection system: M12, M23 connector or cable outlet
  • Enclosure rating: IP 67 (housing), IP 65 (shaft)
  • Operating temperature: -30 °C to +100 °C (depends on type)
Артикул: 150216
  • High-resolution absolute encoders with up to 30 bits (AFM60) or up to 18 bits (AFS60)
  • Face mount flange, servo flange, blind or through hollow shaft
  • SSI, SSI + Incremental or SSI + Sin/Cos interface
  • Programmable resolution and offset (dependent on type)
  • Connection system: M12, M23 connector or cable outlet
  • Enclosure rating: IP 67 (housing), IP 65 (shaft)
  • Operating temperature: -30 °C to +100 °C (depends on type)
